Length: |
19.4 inches (492mm) |
Front Track: |
8.1 inches (204mm) |
Rear Track: |
8.0 inches (202mm) |
Total Width (mirrors): |
8.9 inches (227mm) |
Ground Clearance: |
0.3 inches (9mm) |
Weight: |
3.92lbs (1.78kg) with body (no battery) |
Height (ride): |
5.1 inches (130mm) |
Wheelbase: |
11.3 inches (288mm) |
Shock Length: |
Short (front and rear) |
Tire Diameter: |
2.8 inches (73mm) |
Tire Width (front): |
1.1 inches (28mm) |
Tire Width (rear): |
1.3 inches (32mm) |
Wheel Diameter: |
2.1 inches (54mm) |
Speed Control: |
XL-5™ Waterproof FWD/REV ESC with Low Voltage Detection (LVD) |
Motor (electric): |
Titan® 12T 550 (12-Turn) |
Transmission: |
Single Speed Direct Drive |
Overall Drive Ratio: |
11.38 |
Differential Type: |
Sealed, Hardened Steel Bevel, Limited Slip |
Gear Pitch: |
48 |
Chassis Structure/Material: |
Molded Tub / Nylon Composite |
Brake Type: |
Electronic |
Drive System: |
Shaft-Driven 4WD |
Steering: |
Dual-Bellcrank |
Radio System: |
TQ™ 2.4GHz Transmitter |
Servo: |
#2075 High Torque Waterproof |
Top Speed: |
30+mph (with included optional pinion gear) |
Skill Level: |
1 |
Battery Tray: |
158mm long / 46mm wide / 23 or 26mm high |
